Design: Queued + Streamed Sync Invocation

1. Goal​

Route all invocations (including today's "sync") through Redis to a separate worker. The worker executes via the streaming path and publishes output events; the open HTTP request relays them live and ends with the final result. Debug logs (print / console.log) appear only in dev.

2. Locked decisions​

DecisionChoice
Client contractSSE stream; content negotiation — Accept: text/event-stream → SSE, else buffered final JSON
Live transportRedis, per-invocation channel (implemented as a Redis Stream, see §6)
Worker topologySeparate process from the API; no in-memory hub
Output typesdebug logs → dev only; generator chunks + final result → all envs
Dev gatingresolved invocation env == "dev"

3. Current state (recap)​

  • Sync (scheduler.Invoke) calls executor.Run() inline and writes the DB once. Single JSON body.
  • Async (InvokeAsync) enqueues redisstore.Job on velane:jobs; worker BRPOPs and runs exec.Run() (buffered), writes DB once, optional webhook.
  • Stream (InvokeStream) calls exec.RunStream() directly in the API process (no worker), relays SSE; stderr is dropped in stream mode, and stdout carries both logs and the return value with no separation.
  • StreamChunk{Data, Error, Done} — no type tag, no log/result distinction.
  • Worker runs in-process today but is structured to be a separate deployment.

4. Target architecture​

client ──(SSE or JSON)──► control-plane: InvocationsHandler
        │ 1. resolve snippet/version/env, create invocation (pending)
        │ 2. open Redis Stream reader at "$" for inv:<id>:events
        │ 3. enqueue job on velane:jobs
        ▼
      Redis (jobs list + per-invocation event stream)
        ▲ BRPOP
        │
     worker (separate replica)
        │ status→running
        │ RunStream(spec) → executor runtime (Bun/Python)
        │ for each typed event: XADD inv:<id>:events
        │ env != dev → drop "log" events
        │ on finish: XADD {result}/{error} + {done}; finalize DB row
        ▼
handler XREADs events:
   - SSE caller: forward each as an SSE event; close on {done}
   - JSON caller: accumulate; on {done} return final JSON body

Postgres stays the durable record (final write, optional checkpoints). Redis carries the live feed. No in-memory hub, since the worker is a separate process.

5. Event protocol (the core of this change)​

A single typed envelope flows harness → runner → worker → Redis → handler. NDJSON between subprocess and runner; JSON objects on the Redis Stream.

{"type":"log","stream":"stdout","text":"fetching user…","ts":169...}
{"type":"log","stream":"stderr","text":"warn: retrying","ts":169...}
{"type":"chunk","data":"partial output","seq":3}
{"type":"result","output":{...},"duration_ms":812,"exit_code":0}
{"type":"error","message":"handler raised: …","exit_code":1}
{"type":"done"}

Rules:

  • log = debug output (print / console.log / stderr). Dropped by the worker when env != "dev".
  • chunk = intentional generator/streamed output. Always forwarded.
  • result = the handler return value. Always forwarded (terminal-ish).
  • error = terminal failure.
  • done = stream end sentinel; always last.

This is the piece that didn't exist before: it lets us separate "the answer" from "debug noise" and gate the noise by env without losing the result.

6. Why Redis Streams over raw pub/sub​

The conceptual choice was pub/sub; we implement it as a Redis Stream (XADD / XREAD) per invocation because it's a superset that removes real footguns:

  • No lost-message race. Subscribe-before-enqueue makes raw pub/sub mostly safe, but any reconnect loses everything. Streams retain events.
  • Resume / reconnect. UI can reconnect with Last-Event-ID and replay from offset (SSE id: field maps cleanly to stream IDs).
  • JSON (buffered) callers can XREAD the whole thing after completion — same data path, no special casing.
  • TTL / trim with XADD MAXLEN + key expiry bounds memory.

Key: velane:inv:<invocationID>:events, set short TTL (e.g. a few minutes past completion). For prod (no logs) this stream is tiny — just chunk (maybe), result, done.

7. Component-by-component changes​

Harness (Bun runner.ts + Python runner.py)

  • Intercept print / console.log / console.error → emit {"type":"log",...} lines instead of raw writes.
  • Emit handler return as {"type":"result",...}; generator yields as {"type":"chunk",...}.
  • Read subprocess stderr concurrently (fixes the dropped-stderr bug) and tag as log / error.
  • Streaming harness emits the same envelope; non-stream /run can keep returning a buffered result but should also adopt the envelope for consistency.

Executor interface (interface.go)

  • Extend StreamChunk with Type and Stream (and Output any for result). The remote executor's SSE parser passes typed events straight through.

Remote executor (remote/executor.go)

  • RunStream already parses data: SSE lines into StreamChunk; update to carry the new fields. (Firecracker stub mirrors it.)

Redis store (store/redis/)

  • New file: per-invocation event stream helpers — PublishEvent(ctx, invID, event), ReadEvents(ctx, invID, lastID) (events, nextID), plus key TTL / trim. Keep queue.go (jobs list) as-is.

Worker (worker/worker.go)

  • For queued-streaming jobs, switch process() from exec.Run() to exec.RunStream().
  • For each event: if env != "dev" and type == "log", skip; else XADD to the invocation stream.
  • Set status running at start; on terminal event, finalize DB (UpdateInvocationResult) with output / stderr / status — same as today. Optionally checkpoint periodically.
  • Async + webhook behavior unchanged for async-mode jobs.

Job model (redisstore.Job)

  • Add a mode / flag (e.g. Stream bool or reuse InvokeMode) so the worker knows to stream-and-publish vs. the legacy buffered async path.

Scheduler (scheduler.go)

  • New method (e.g. InvokeQueued) that: resolves version, creates invocation (pending), enqueues the job, and returns the invocation ID without running the executor. The handler owns the Redis read loop.
  • Old Invoke (inline) can be kept temporarily behind a flag for rollback, or removed once callers move.

Handler (invocations.go)

  • Content negotiation on Accept.
  • Order: open the stream reader (at $) → enqueue → read loop. (Even with Streams, opening first avoids a cold-start gap.)
  • SSE path: forward events, set SSE id: to the stream ID for resume, close on done.
  • JSON path: accumulate, return one body on done (logs included only if dev).
  • Timeouts: if no worker emits running / first event within N seconds → 503 / timeout event. Respect client disconnect (cancel read; worker keeps running and finalizes DB).

DB

  • Final record unchanged (output, stderr, error, status, duration_ms).
  • Logs are ephemeral (Redis only). Open question: do we want dev logs persisted for the Logs tab, or live-only? (see §10).

8. Dev-gating logic​

  • Single point of enforcement: the worker, keyed on the resolved job.Env == "dev". log events are dropped before XADD in non-dev. This guarantees prod debug output never even reaches Redis, the client, or storage — clean security boundary.
  • chunk and result are never gated.

9. Caller migration​

CallerTodayAfter
Admin UI "Run"sync JSONSSE: render chunk / result in Output panel, log in Logs terminal (dev only)
Admin Logs tabplaceholderlive SSE feed + historical via get_logs
MCP invoke_snippetbuffered JSONunchanged contract — server buffers stream, returns final JSON (logs field only in dev)
CLI invokeJSONdefault JSON (buffered); --stream already exists → SSE
curlJSONJSON unless Accept: text/event-stream

Net: with content negotiation, MCP / CLI / curl keep working unchanged; only the UI opts into SSE.

10. Resolved decisions (as implemented)​

  1. Dev logs are live-only (Redis Streams, ephemeral, ~5 min TTL). No DB column added; the Logs tab shows the current run's stream. A durable log table can be added later.
  2. No-worker / stall handling: the handler uses a 90s idle timeout and a 5 min hard cap, after which it emits a terminal done with error:"timeout". A background reaper (FailStaleInvocations, 1 min tick, 10 min staleness) marks rows stuck in pending/running as timeout.
  3. Client disconnect: the worker keeps running and finalizes the DB regardless; the JSON path reads the final row with a background context.
  4. Stream bounds: event stream is XADD MAXLEN ~10000 with a 5 min key TTL.
  5. Inline Invoke retained as a fallback: when Redis is unavailable (HasEventStream() is false), sync uses the inline executor path and stream uses the legacy direct SSE path. With Redis present, both route through the queue.
  6. Scopes unchanged: the invoke endpoint keeps its existing auth (invoke scope / membership role) and tenant resolution.

Transport selection (as implemented)​

SSE is returned only when the caller sends Accept: text/event-stream; otherwise a buffered JSON body is returned once the worker finalizes. This applies to both sync and stream modes, so MCP (which sends no such header) always receives aggregated JSON, while the CLI --stream and the admin UI opt into SSE.

11. Edge cases / failure modes​

  • No worker available → timeout event / 503; invocation stays pending then marked failed by a reaper (need to define) or left for retry.
  • Worker crash mid-job → no done; handler hits read timeout; invocation needs a stale-running reaper to mark failed.
  • Redis down → no queued path; either hard-fail or fall back to inline Invoke (decision tied to Q5).
  • Stream race → solved by open-reader-before-enqueue + Streams retention.
  • Slow client → backpressure on the HTTP write; worker is decoupled (writes to Redis), so a slow client can't stall execution.
  • Duplicate delivery / at-least-once → events carry seq / stream IDs; consumers are idempotent (last result / done wins).

12. Phasing (completed)​

  • Phase 1 — protocol + plumbing (done): typed StreamChunk envelope; Bun + Python streaming harnesses rewritten to emit log/chunk/result/error/done and redirect user stdout/stderr to typed log events; Redis per-invocation event-stream helpers (PublishEvent/ReadEvents, events.go); Job.Stream flag; worker streaming path with dev-gating and DB finalize-before-done ordering.
  • Phase 2 — handler + callers (done): Scheduler.InvokeQueued + HasEventStream/ReadEvents; content-negotiating SSE / JSON handler (invokeQueuedMode); CLI --stream sends the SSE Accept header; MCP unchanged (buffered JSON); admin UI streams the run and splits Output vs. Logs; stale-invocation reaper in main.go.

Tests​

  • go test ./... green across control-plane, mcp-server; CLI builds. go vet clean.
  • New unit tests cover dev-gating: TestWorker_StreamJob_DevForwardsLogs and TestWorker_StreamJob_ProdDropsLogs.
  • npx tsc --noEmit clean for the admin app.
  • DB/Redis-backed integration tests skip without TEST_DATABASE_URL / TEST_REDIS_URL; the buffered SSE round-trip is best validated end-to-end via make up.
